KNX / DALI GATEWAY

KNX / DALI GATEWAY

ORDERING CODE
2098 REGHE

DESCRIPTION
Device working as a gateway (protocol conversion) between a DALI network and a KNX (TP) network. It is intended for the control of luminaires and other applications with DALI operating device in KNX installations. Mounting in distribution board on EN 60715 rail (4 modular units). To be used in KNX installations for home and building automation.

FUNCTIONS / CHARACTERISTICS

  • Control of up to 64 DALI devices in up to 32 groups
  • Individual, group or central addressing
  • Suitable for operation in emergency lighting systems
  • 16 light scenes
  • Effect control for dynamic lighting effects or colour games
  • Read out DALI device state via KNX, e.g. brightness or luminaire error
  • Manual operation of the DALI groups
  • Restraint
  • Feedback of switching state and brightness value in bus and manual mode
  • Collective feedback
  • Central switching function
  • Disabling function for each DALI group
  • Separate ON and OFF delay
  • Staircase lighting timer with pre-warning function
  • Corridor function: when combined with motion detectors, reduced continuous lighting, if no motion is detected
  • Online or offline project design of the DALI devices with ETS plug-in
  • Short-circuit protection
  • Surge protection
  • Overload protection
  • Operating hours counter
  • Signal of the global switching status of the DALI devices, e.g. to switch off the mains voltage of the DALI devices to avoid standby losses
  • An individual DALI device can be exchanged during operation without software
